Campagnolo Euclid (Graphite Finish)
Back
Report
Main Photo
Category:  Front Derailleurs
Name:  Campagnolo Euclid (Graphite Finish)
Brand:  Campagnolo
Primary Group:  Euclid
Model:
Years:  1990 - 1991
Country:  Italy
Weight:  115 grams (Actual)
Added By: JFischer on 12/24/10
Updated By: JFischer on 12/24/10
Additional Photos - click for full size
Campagnolo Euclid (Graphite Finish)Campagnolo Euclid (Graphite Finish)
 Verify Component Photos
# Rings Designed For TripleOuter Plate MarkingsCampagnolo shield
Inner Plate MarkingsBrev. Inter Made in ItalyClamp MarkingsNone
Inner Clamp MarkingsDesign CategoryParallelogram
Pivot Arm MarkingsNonePlate MaterialSteel
Clamp Style28.6mm ClampCable Attachment Bolt5mm Allen Key
CableStop NoClamp Bolt Type5mm Allen Key
Max Ring Difference 26T
General Information

Quality:Rarity:


See Incorrect Information? Log-in to submit report.
Additional Resources
Resources:Reference & ChartsCatalogsExternal Resources
Component VariationsView Detailed List  Manage Variations
Variations of Component exist (Component is 1 of 3)BrandGroup
Campagnolo M022, EuclidCampagnoloEuclid
Campagnolo M023, EuclidCampagnoloEuclid
Component Groups
Primary Group NameBrandQuick InfoBrowse Group Components
EuclidCampagnolo1989 - , Mountain BikeView 26 Components
